MPO MTP Fiber Optical Connectors

An MPO/MTP connector is a fiber optic connector comprised of multiple optical fibers such as 8/12/24 core,etc. Larger core counts are also available and are typically found in super high-density applications.An MPO cable assembly contains optical fibers,sheath, dust cap and the connector coupling components, which include metal spring, guide pins and ferrules. MPO/MTP connectors are either male or female.The male connector has two pins, whereas the female connector does not have any pins.

MPO/MTP connectors have a key on one side of the connector body which helps to determine the fiber positions and ensures that the connector can be inserted only one way into an MPO/MTP adapter or transceiver port. An MPO/MTP connector with 8, 12, and 24 fibers will have the key in the center of the housing.
Product inquiry
Product Details

GoodFtth provides a full range of fiber connector kits and fiber adapters for SC,FC,ST,LC,MU,MTRJ,E2000,SMA,MPO/MTP configurations. We supply singlemode,multimode,angle-polished fiber connector assemblies with stable qualities that use high quality ceramic ferrules.




Application:

Telecommunication System

Testing Equipment

CATV System

LAN System



Feature:

High Precision Alignment, Easy for Operation
Good Repeatability and Exchangeability

Low Insertion Loss,High Return Loss

Good Stability


Specification:

Parameter

MPO/MTP Connectors

SM

MM

APC

PC

Insertion loss

0.35dB

0.35dB

Return Loss

≥60dB

≥20dB

Operating Wavelength

1310nm, 1550nm

850nm, 1300nm

Ferrule Concentricity

≤1um

≤4um
