Distribution cable is the most popular multi-fiber indoor cable, as it is in small size and light weight. Such cable contains several tight-buffered fibers bundled under the same jacket with aramid yarn strength members, this has made the distribution cable to be easily handled and stripped for field termination.
Application:
Indoor distribution;
For patchcords and pigtails;
For communication equipment.
Feature:
Soft and flexible;
Excellent flame retardant performance;
Excellent tensile&crush strength;
Cable sheath options:PVC,LSZH,OFNP,etc.
Mechanical Characteristics:
Fiber Count | Cable Dimension (mm) | Cable Weight (kg/km) | Tensile Strength (N) | Crush Load (N/100mm) | Min.Bending Radius (mm) | Temperature Range (℃) | |||
Long Term | Short Term | Long Term | Short Term | Dynamic | Static | -20~+60 | |||
4 | 5.0 | 19.0 | 130 | 440 | 200 | 1000 | 20D | 10D | |
6 | 5.2 | 23.0 | 130 | 440 | 200 | 1000 | |||
8 | 5.5 | 26.0 | 130 | 440 | 200 | 1000 | |||
12 | 6.5 | 36.5 | 200 | 660 | 200 | 1000 | |||
16 | 7.5 | 44.5 | 200 | 660 | 200 | 1000 | |||
24 | 8.0 | 54.5 | 200 | 660 | 200 | 1000 | |||
36 | 9.0 | 72.0 | 200 | 660 | 200 | 1000 | |||
48 | 10.5 | 90.0 | 200 | 660 | 200 | 1000 | |||
Fiber Count | Sub-unit Count | Fiber Count in Each Unit | Cable Dimension (mm) | Cable Weight (kg/km) | Tensile Strength (N) | Crush Load (N/100mm) | Min.Bending Radius (mm) | Temperature Range (℃) | |||
Long Term | Short Term | Long Term | Short Term | Dynamic | Static | -20~+60 | |||||
16 | 4 | 4 | 12.5 | 125 | 400 | 1320 | 300 | 1000 | 20D | 10D | |
24 | 6 | 4 | 15.0 | 183 | 400 | 1320 | 300 | 1000 | |||
36 | 6 | 6 | 17.0 | 238 | 400 | 1320 | 300 | 1000 | |||
48 | 6 | 8 | 18.5 | 292 | 400 | 1320 | 300 | 1000 | |||
64 | 8 | 8 | 22.0 | 410 | 400 | 1320 | 300 | 1000 | |||
72 | 6 | 12 | 22.5 | 390 | 400 | 1320 | 300 | 1000 | |||
96 | 8 | 12 | 25.5 | 546 | 600 | 1500 | 300 | 1000 | |||
144 | 12 | 12 | 33.5 | 1004 | 800 | 2000 | 300 | 1000 | |||
Optical Characteristics:
|
| G652D | G657A1 | G657A2 | G.655 | 62.5/125 | 50/125 |
Attenuation | @850nm |
|
|
|
| ≤3.0dB/km | |
@1300nm |
|
|
|
| ≤1.0dB/km | ||
@1310nm | ≤0.36dB/km |
|
| ||||
@1550nm | ≤0.22dB/km | ≤0.23dB/km |
|
| |||
Bandwidth | @850 |
|
|
|
| ≥500MHZ·km | |
@1300 |
|
|
|
| ≥600MHZ·km | ≥1000MHZ·km | |
Numerical Aperture |
|
|
|
|
| 0.275±0.015NA | 0.200±0.015NA |
Cut-off Wavelength |
| ≤1260nm | ≤1480nm |
|
| ||
Note: 1.Available Fiber:G652,G655,G657 or OM1,OM2,OM3,OM4,OM5;
2. Jacket Material:PVC,LSZH,HYTREL ,OFNR,OFNP or customized;
3. Regular Jacket Color:Yellow for singlemode;Orange for multimode (OM1/ OM2);
Aqua for OM3,Magenta for OM4,Lime Green for OM5.
